1. The ZS series layered sieve is suitable for flow operations and is an ideal equipment for continuous discharge of materials with different particle ratios.
2. This machine consists of a hopper, an oscillation chamber, and an oscillation motor. This machine achieves material grading by adjusting the eccentricity of the oscillating motor, and the size of the eccentric wheel of the oscillating motor can be adjusted.
3. The whole machine has a compact structure, small size, no dust, low noise, high quality, low energy consumption, and is easy to move and maintain.
| model | production capacity(kg/h) | Number of sieving mesh (mesh) | Electric power (kw) | Spindle speed (r/min) | Dimensions (mm) | Weight (kg) |
| ZS-350 | 60-500 | 12-200 | 0.55 | 1380 | 540×540×1060 | 100 |
| ZS-515 | 100-1300 | 12-200 | 0.75 | 1370 | 710×710×1290 | 180 |
| ZS-650 | 180-2000 | 12-200 | 1.50 | 1370 | 880×880×1350 | 250 |
| ZS-800 | 250-3500 | 5-325 | 1.50 | 1500 | 900×900×1200 | 300 |
