The CH series trough mixer is used to mix powdered or wet materials, ensuring uniform mixing of different proportions of main and auxiliary materials. The machine is made of stainless steel at the contact point with the material, with a small gap between the blade and the barrel, and no dead corners in the mixing process. The mixing shaft is equipped with sealing devices at both ends to prevent the material from spilling out. The hopper is controlled by a button for easy discharge. Widely applicable to industries such as pharmaceuticals, chemicals, and food.
model | capacity(L) | Motor power(kw) | Overall dimensions(mm) | stirring speed(rpm) | Pouring angle(。) | weight(kg) |
100 | 100 | 2.2 | 1400×580×1000 | 24 | 105 | 350 |
150 | 150 | 3 | 1600×600×1050 | 24 | 105 | 500 |
200 | 200 | 3 | 1870×650×1065 | 24 | 105 | 650 |
